Shape and size chart (mm)
Model |
A φ |
Interface calibre Rc (PT) |
BP-1S |
17.5 |
3/8 |
BP-2S |
22.0 |
1/2 |
BP-3S |
27.5 |
3/4 |
|
FG Series
Applicable to the middle and low-pressure flow
There are a variety of options with different uses built
Easily replaced filters
Shape and size chart (mm)
Model |
Built length |
A |
B |
Rc (PT) |
Weight (kgf) |
FGDC
Fgde |
A (L250) |
314 |
346 |
3/8,1/2,3/4 |
1.3 |
B (L500) |
574 |
606 |
3/8,1/2,3/4 |
2.2 |
Fgdt
FGDF |
A (L250) |
315 |
349 |
3/8,1/2,3/4 |
2.3 |
B (L500) |
574 |
608 |
3/8,1/2,3/4 |
3.8 |
|
